Engine Type: OHV longitudinally mounted single-cylinder four-stroke Displacement: 518cc Cylinders: 1 Bore x Stroke: 96mm x 71.5mm Engine Cooling: Liquid Fuel System: PGM-FI Starting System: Electric with optional auxiliary recoil Front Suspension: Independent double-wishbone Front Travel: 7.28 in. Front Brake Type: Dual hydraulic 190mm disc Front Tires: 25 x 8-12 Rear Travel: 7.28 in. Rear Suspension: Swingarm with single shock Rear Brake Type: Sealed 160mm mechanical drum Rear Tires: 25 x 10-12 Dry Weight: Curb Weight: 636 lb. Front Rack Capacity: 88 lb. Rear Rack Capacity: 176 lb. Fuel Capacity: 3.9 gal., including 1.3-gal. reserve Ground Clearance: 7.5 in. Machine Dimensions (LxWxH): 82.8 in. x 47.4 in. x 48.0 in. Wheelbase: 50.0 in. Final Drive: Direct front and rear driveshafts with TraxLok and front differential lock Transmission: Five-speed with Reverse Colors: Red, Olive
