Engine Type: 4-stroke, single; SOHC, 4 valves Displacement: 686cc Bore x Stroke: 102.0mm x 84.0mm Cylinders: Single Engine Cooling: Liquid Fuel System: Yamaha Fuel Injection (YFI), 44mm Starting System: Electric Front Suspension: Independent double wishbone; 5-way preload adjustment Front Travel: 7.6 in. Front Brake Type: Dual hydraulic disc Front Tires: AT25 x 8-12 Rear Travel: 9.2 in. Rear Suspension: Independent double wishbone; 5-way preload adjustment Rear Brake Type: Dual hydraulic disc Rear Tires: AT25 x 10-12 Dry Weight: Curb Weight: 648 lb. Front Rack Capacity: 99 lb. Rear Rack Capacity: 187 lb. Towing Capacity: 1322 lb. Fuel Capacity: 5.3 gal. Ground Clearance: 10.8 in. Machine Dimensions (LxWxH): 81.3 x 46.5 x 48.8 in. Wheelbase: 49.2 in. Drive Train: Yamaha On-Command® pushbutton; 3-way locking differential; 2WD, 4WD, locked 4WD; shaft drive Final Drive: Shaft Transmission: Yamaha Ultramatic® V-belt with all-wheel engine braking/H, L, N, R, P Speedometer: Standard: Digital Odometer: Standard: Digital Lighting: Dual headlights and 21/5W brakelight Colors: Hunter Green, Steel Blue, Red
